Microscopes can clearly see the video on the surface of a LaserDisc, discovers Techtuber — a 12-inch vinyl-like disc that stores SD analog video

News
By published

Developed by RCA during the video cassette tape era, CED was an expensive flop.

Old video disc formats under a microscope
(Image credit: Tech Tangents )

Tech Tangents (TT) surprised themselves by looking at the surface of a CED ‘LaserDisc’ under a microscope and felt compelled to purchase a new device, with a built-in screen and HDMI out, to share what they had discovered. Spoiler alert: You can clearly see some of the analog imagery stored on a CED surface.

Microscopes can See Video on a LaserDisc - Andonstar AD246S-P - YouTube Microscopes can See Video on a LaserDisc - Andonstar AD246S-P - YouTube
Watch On

Like its tape format rivals, the video content stored on a CED was in a standard-definition quality analog form. So, looking extremely closely at the grooved surface can actually give you more than a clue to the content of the disc.

Article continues below

Enjoying the new microscope

After introducing his new microscope and its capabilities, TT finally gets down to some close-up disc scrutiny at around the 14mins mark. Specifically, he zooms in on the surfaces of two samples of actual LaserDiscs. These contain generally better quality (though still analog) video tracks, which were read by a laser pickup. Some of the later LaserDiscs were enhanced with digital PCM audio tracks.

One of the LaserDiscs examined closely was a CAV (Constant Angular Velocity) disc, with its data evidenced by a consistent geometric pattern, whereas a CLV (Constant Linear Velocity) disc under the microscope looks simply colorfully streaky.

(Image credit: Tech Tangents )

“I found an image!”

Now studying the LaserDisc surface more earnestly, something caught TT’s eye. “It's not going to happen. We're not going to find an image.” Then, almost immediately, “I found an image.”

The video host explains what we are seeing and that, due to the nature of the LaserDisc recording and media, it is possible to see a “meaningful” image on the surface, if and when the video slowly pans across the x or y axis. The first evidence of this phenomenon comes from some video text shown at around 22min 30sec in the video (see image, above).

CED QED

The main event takes place around 25 minutes into the video. A CED disc is (at last) placed under the microscope. After a bit of zooming, focusing, and angling of light sources, TT blurts, “Oh my gosh. We just nailed it. Bang. Right there.”

(Image credit: Tech Tangents )

Again, it is some text, but this time a much clearer representation of the disc content. The CED surface text is almost as clear as a stored video frame on some old film.

After that excitement, the video host moves along to look at a couple of other tech-related artifacts under the microscope. The extras include a surface study of a mixed-mode audio/data CD, and a smartphone screen close-up where the OLED (sub) pixels are clearly visible.

If you reckon the demonstrated desktop digital microscope is a good one, it is the Andonstar AD246S model. We have noticed it is currently 13% off and available for $139 on Amazon.
